Tire Aging Oven
Model :
EKT-2110-TAO
The EKT-2110-TAO is an industrial-grade Whole Tire Aging Oven designed for PCR and TBR testing. Engineered to overcome the challenges of massive chamber testing, it features automated VOC exhaust safety systems, heavy-duty trolley loading, and dynamic airflow circulation that guarantees strict temperature uniformity up to 200°C.
Engineered for Massive Scale & Ultimate Safety
Dynamic Airflow & Temperature Uniformity
Achieving thermal consistency in a massive chamber is critical. The EKT-2110-TAO utilizes a highly calibrated dynamic airflow circulation system. This ensures that every inch of the massive tire—from the heavy tread to the thinner sidewalls—is exposed to the exact same aging temperature, eliminating "cold spots" and ensuring globally compliant test data.
Automated VOC Exhaust & Safety
Heating large volumes of rubber generates immense amounts of toxic and potentially flammable Volatile Organic Compounds (VOCs).
- Equipped with a powerful, automated ventilation and exhaust system.
- Continuous fresh air exchange prevents dangerous gas build-up.
- Ensures uncompromising safety for laboratory personnel.
Technical Specifications (EKT-2110-TAO)
| Test Capability | Whole Tire Aging (PCR / TBR) |
|---|---|
| Temperature Range | Room Temperature ~ 200°C (Adjustable) |
| Temperature Uniformity | ± 1.5°C (via Dynamic Airflow) |
| Ventilation System | Automated VOC Exhaust with adjustable air-exchange rate |
| Loading Mechanism | Heavy-duty slide racks / Optional external trolley system |
| Control Interface | Programmable logic controller (PLC) with touch screen |
* Specifications are customizable based on specific tire sizes (PCR, TBR, or OTR) and laboratory requirements.
